Northstar Pontoons - 16'

Northstar Pontoons - 16'

2023
China
Northstar Pontoons

System at a Glance

This 2023 16' is an electric Pontoon from Northstar Pontoons, powered by a 40 kW ePropulsion motor and a 41 kWh battery pack, offering a quiet and eco-friendly boating experience.

Length (LOA)5.74 m (18.8 ft)
Beam (BOA)2.46 m (8.1 ft)
Hull Draft0.3 m (1.0 ft)
Hull ConfigCatamaran
Hull TypeDisplacement
Displacement680 kg (1,499 lbs)
Talk to a Dealer

Electric Propulsion System

Electric Propulsion System

Motor

1 × X40 Electric Outboard Motor-XL

Total Power: 40 kW
X40 Electric Outboard Motor-XL

Batteries

4 × G102-100 Battery

Capacity: 41 kWh
G102-100 Battery 1
G102-100 Battery 2
G102-100 Battery 3
G102-100 Battery 4

Propeller

1 × X20/X40 Propeller 15'' x 10 3/4''

Rated RPM: 1500
Propeller
Top Speed
14.3 kn
Cruising
7.6 kn
Est. Range
13-199 NM

Ready to spec this for your boat?

Our team will match motors, batteries, and cabling to your hull and duty cycle.

Talk to a Dealer
  • Make & Model
    Northstar Pontoons 16' (2023)
    Hull Type
    Displacement
    Configuration
    Catamaran
    Prop Diameter
    380.00 mm
    Prop Pitch
    270.90 mm
    Prop Rated RPM
    1500
  • LOA
    5.74 m
    Beam (BOA)
    2.46 m
    Draft
    0.30 m
  • Displacement
    680 kg
    Motor & Battery
    502 kg
    Total Weight
    1,182 kg

Interested in this Boat?

This Northstar Pontoons 16' was listed by ePropulsion HQ,

Reach out for performance details, configuration advice, or to locate a nearby dealer.
