G102-100

Battery

G102-100 Battery

Lithium Iron Phosphate
Battery (LiFePO4)
Lithium Iron Phosphate Battery (LiFePO4)

High-performance and durable lithium ironphosphate battery for electric boating

10240 Wh / 96 V

Why Choose
G102-100 Battery

Why Choose G102-100 Battery

Fully Compatible
with ePropulsion Motors

Power the 96V 10kW to 40kW ePropulsion motors including the I-Series inboards.*

Power the 96V 10kW to 40kW ePropulsion motors
including the I-Series inboards.*
Maximum safety
Made with LFP, the built-in intelligent battery management system (BMS) is applied to provide maximum safety for the users.
Long Life Cycle
3,000 cycles at 80% DOD, the G102-100 lifepo4 battery powers your motors much longer than lead-acid
batteries.**
High Energy Density
3 times higher energy density and 70% less weight
than lead-acid batteries.**
Easy to Install

Connectors can be installed with only ONE hand, and
the battery saves wiring harness connection compared
to series-parallel connection of battery.

Connectors can be installed with only ONE hand, and the battery saves wiring harness connection compared to series-parallel connection of battery.

High Reliability
All-metal housing is more reliable, weather resistant,
impact resistant and drop proof.
* G102-100 can be connected in parallel to power different ePropulsion motors.
** Under equal capacity.

Design

Specs

ChemistryLithium Iron Phosphate (LiFePO4)
Rated Voltage102.4 V
Capacity10240 Wh / 100 Ah
Battery Life3,000 cycles at 80% DOD
Weight100 kg
Dimensions680 x 500 x 300 mm (26.8 x 19.7 x 11.8 in)
Cut-off Voltage83.2 V
Final Charging Voltage115.2 V
Max Continuous Discharging Current100 A
Serial ConnectionN/A
Parallel ConnectionUp to 4 in 1 cluster. Multiple clusters are possible in the system
Cell Configuration32S1P
Charging Temperature0 to 55℃
Discharging Temperature-10 to 60℃
CommunicationOne CAN for ePropulsion motors / One CAN (Two ports) for parallel
batteries / One CAN for charger
Shipping ClassificationUN3480, Class 9, UN38.3 Certified
ApprovalsCE, UKCA, FCC
Warranty (Non-Commercial Use)2 years

FAQ

Why choose G102-100 battery over 3rd-party option?

  • Fully Compatible with ePropulsion Motors, G102-100 powers 96V 10kW to 40kW ePropulsion motors including the I-Series inboards. Through the internal communication protocol, the G102-100 can present battery status information and high precision data (eg: SOC). Working in synergy with the outboard/inboard motor and energy system, the battery provides the customer with a better power experience.
  • The G102-100 is a lithium iron phosphate battery (LiFePO4) with a single pack of 102V, a built-in BMS, a full metal housing and IP67 protection design for greater safety and reliability.

Can I use a third-party charger for my G102-100 Battery?

No. Third-party chargers are not allowed for warranty reasons. Please consult with your dealer or ePropulsion after-sales service team on Facebook if you have any special needs.

What is the function of terminal resistance?

Terminal resistance is used to ensure the quality of communication and reliability when the batteries are connected in parallel.

How do I turn on and turn off the G102-100 battery?

The G102-100 battery has a power button that can be pressed to turn the battery on and off.
When the G102-100 battery is working in connection with the ePropulsion motor, users can turn the motor on or off directly. The motor will automatically turn the battery on and off.

Can G102-100 battery be used in series?

No. The G102-100 operates at 102V and can only be connected in parallel, not in series.
